FireBOX GA
FireBOX GA
The FireBOX GA is an inline pre-filter engineered to mitigate fire risks in non-metal applications. It safeguards the extraction system by self-extinguishing in the rare event an ember is drawn into the system.
- Reduces hazard
- Suppresses fire
- Isolation valves
- Thermal flow cut-out
Approvals: UKCA and CE
Features
DeepPleat DUO pre-filter
Our DeepPleat DUO pre-filter is designed to maximize filter life. It incorporates a large capacity drop-out chamber within the filter which is designed to act as a pre-separator helping to extend the life of the pre-filter which in turn protects against the premature blocking of the HEPA filter.
Reverse flow air technology
Our reverse flow air technology reduces velocity and changes air direction, causing larger particulate to fall into the filter’s drop-out chamber. This decreases particulate entering the filter media, significantly enhancing filter capture performance, and extending filter life.
Multi-voltage sensing
Automatically senses the local voltage and adjusts accordingly.
Technical specification
| Imperial | Metric | |
|---|---|---|
| Dimensions (including beacon) | 46.65 x 19.49 x 25.20” | 1185 x 495 x 640 mm |
| Weight | 123 lbs | 56 kg |
| Airflow / Pressure | Up to 294 cfm | Up to 500 m³/hr |
| Electrical data | 115-230 V 1 ph50/60 Hz Max load current: 13 amps | 115-230 V 1 ph50/60 Hz Max load current: 13 amps |
| Cabinet construction | Brushed stainless steel | Brushed stainless steel |
